Equipment trailer GRAVIS 2000

2-axleconstructionagricultural

Because besides bulk and agricultural materials also heavy bulk material like sand, gravel, soil material or recycling material has to be transported more often, professional farmers and contractors will line up their fleet to a wider spectrum of materials. Consequently, Gravis is the powerful machine industry-wide long-term use. The robust construction of the frame unit and the hollow enable a technical payload of approximately 26 tones. The usage of solid, wear material has a positive effect on the working life of the machine. The high-quality serial equipment packages as well as options help the user to keep an overview also in hard working conditions. Sturdy frame made f rom steel square tube 300 x 200 x 8 mm, spring-loaded shock absorbers on towing bar, low drawbar hitch with fix towing eye D40 mm (adjustable height, connection height approx. 610/650/690 mm), landing gears (with gear box, double speed, three-stages), préparation for trailer coupling, underride guard with commercial LED road lighting system,, wheel chocks Heavy duty ADR-axIes with 10-stud rims, track 1950 mm, wheelbase 1550 mm, axle load 16500 kg/axle, brake cam 420 x 180 4218E Dual line air brake installation (sélection according to country) Conical dumper body made of steel plate (8 mm HARDOX®- floor and 6 mm walls), hydraulic tailgate (with double-acting cylinders and hydraulic accumulator), automatic closing for secure locking
