Truck tire changer RGU566E

for agricultural vehiclessuperautomatichorizontal

Universal Tire Changer for trucks, agriculture and earth-moving wheels: is a professional unit, super-automatic designed for tire service shops with heavy work load of commercial / agriculture / earth-moving wheels up to 46" (56" optionally). Technical Features - Super Automatic Truck Tyre Changer for Trucks, Agricultural and Earth Moving vehicles - Suitable for groove rims and split ring rims - Suitable for normal and tubeless tires - Self-centering hydraulic chuck with 4 clamping jaws - 2 speed Motor - Clockwise and anticlockwise rotation of the chuck - Universal toolhead - Chuck on fixed arm - Hidraulic lifting of chuck up-down - Electro-Hydraulic displacement (left right ) of the arm that contains the toolhead. - Toolhead with automatic lifting and automatic rotation - Mobile remote control (low voltage) - Mobile ramp for easy positioning of the wheel - Hydraulic pump motor 1,5 kW (2,0 Hp) - Safety valve on hydraulic circuit - Chuck Gearbox motor 1,8 kW (2,4 Hp) - Spindle shaft working height min 350 mm - Bead breaking force (in/out) 36 kN - Max rotation torque 5,2 kN - Clamping force max 48 kN - Rim central hole min 80 mm - Max wheel weight 1800 kg - Rim diam. 14-46" (opt. 56") - Max wheel diam 2400 mm (94") - Max wheel width 1300 mm (51") - Noise < 70 dB (A) - Compare features of different models.
