Fixed scissor lift HW-C series

hydraulicelectric

ELECTRIC LIFTING PLATFORM HW-C SERIES with perimeter protection The lifting platforms HW-C series are lifting equipment to be installed in a fixed position and are driven by a hydraulic power pack. Manufactured according to accident prevention standards, they consist of two platforms (upper and lower) and a pantograph system actuated by a hydraulic cylinder. The HW-C series is characterized by the perimeter protection bellows. Main Features: - Very strong structure in painted steel - Construction according to CE safety standards - Upper platform in smooth metal sheet - Perimeter protection bellows - Hydraulic unit of European production, positioned internally, designed for intermittent use by 30% - Keypad with low voltage controls - Hydraulic system with a safety valve for overload - Control valve for descent speed - Large hydraulic cylinders with valve fall arrest in case of breakage of the pipes - Antishearing safety distance between the arms of the pantograph - Joints with self-lubricating bushings - Lifting hooks removable for transportation and installation - Suitable only and exclusively for lifting goods with a uniformly distributed load MODEL - HW 1001C - HW 1002C - HW 2001C - HW 2002C Load - 1000 Kg - 1000 Kg - 2000 Kg - 2000 Kg Minimum height - 205 mm - 205 mm - 230 mm - 230 mm Maximum height - 1000 mm - 1000 mm - 1050 mm - 1050 mm Plan dimensions - 900×1400mm - 1000×1600 mm - 950x1400 mm - 1000x1600 mm Base dimensions - 640×1240 mm - 640×1240 mm - 785x1220 mm - 785x1220 mm Lifting time - 20-25 sec. - 20-25 sec - 20-25 sec - 16-22 sec Supply - 380v/50HZ,AC Power - 1,1kw - 1,1kw - 1,5 kw - 1,5 kw Net weight - 160 Kg - 186 Kg - 235 Kg - 270 Kg OPTIONAL: - Pump with external installation and control stand Normally the pump is positioned under the lifting surface. If the platform is installed in particularly confined spaces, it may be difficult to reach the pump group in the event of even minor failures. On request when ordering, we can move the pump to an external position, installing it on a column where a yellow movement remote control is also applied. - Optional PN-PD Control stand with pedal for raising and lowering the platform to replace the remote control. - Reinforcement of the base for lifting and moving with a forklift On request when ordering, the base of the platform is reinforced with steel sections, to allow lifting and handling by forklift. The reinforcing structure is equipped with support feet. OPTIONAL - Increase for modification to the electrical panel for transformation from three-phase model to single-phase model. The change can only be requested at the time of ordering.
