Telescopic arm lifter FP-TEL series

manualpowder coatingwinch

Telescopic lifters for lifting materials with a maximum weight from 85 to 300 kg to a height from 3300 to 5220 mm. TELESCOPIC LIFTERS FOR LIFTING MATERIALS FP-TEL Telescopic winch lifts for lifting material weighing 85, 125, 150, 230, 270 or 300 kg to a height of 3.3, 3.5, 4.5 or 5.2 metres. Lightweight and easy to move, they allow you to easily move and lift audio units such as speakers and boosters, air conditioners, electrical control units, etc. They are easily foldable and take up very little space when not in use. Depending on the model, the lifts can be equipped with a 3 or 4 telescopic section tower and an adjustment system (if provided) to prevent the mast from oscillating during lifting and transport. All models are made of steel finished with a scratch-resistant, corrosion-resistant black epoxy powder coating. They also come with foldable/detachable stands to take up as little space as possible when not in use. Lifting takes place via a self-braking manual winch which stops and keeps the load at the desired height. The winch is equipped with a non-rotating steel cable with an independent galvanized steel core (DIN 3060), specially designed to avoid twisting and curling. All lifts are supplied with steel top included. Models FP-TEL7.0 to FP-TEL7.5 have a mm. 450x450 while the models from FP-TEL7.65 to FP-TEL7.85 have a mm. 800x400. Available models: - FP-TEL7.0: load 85 kg and lifting up to 3300 mm - folding umbrella base - FP-TEL7.2: load 125 kg and lifting up to 3500 mm - folding umbrella base - FP-TEL7.3R: load 125 kg and lifting up to 4580 mm - with wheels - FP-TEL7.5: load 150 kg and lifting up to 4500 mm - with feet - FP-TEL7.65: load 230 kg and lifting up to 5220 mm - with feet - FP-TEL7.75: load 270 kg and lifting up to 5220 mm - with feet - FP-TEL7.85: load 300 kg and lifting up to 5220 mm - with feet Technical Specifications: - Maximum load: 85 to 300 kg (depending on model) - Maximum lifting height: 3300 to 5220 mm (depending on model) - Minimum working height: 1350 to 1750 mm (depending on model) - Weight: 12.8 to 102.5 kg (depending on model) - Base diameter: 1130 to 2250 mm (depending on model) - Number of upright sections: 3 or 4 - Adapters: ø35 mm or ø55 mm - Wheels: 4 swivels with brake (on selected models) - Closed dimensions: varies by model Optional - Steel top 800x400 mm - Aluminum top 740x435-450x435-800x400 mm - Wheels for FP-TEL7.2 model - Cradle for cylindrical products Key Features: - Lightweight and easy to move - Foldable and space-saving - Manual winch with self-braking system - Non-rotating steel cable (DIN 3060) - Scratch and corrosion-resistant black epoxy powder coating - Steel top included (450x450 mm or 800x400 mm depending on model) - Optional accessories available
