Manual lifter FP PS 04 E series

battery-poweredelectro-hydraulicfork

BATTERY LIFTER FOR BOXES AND REELS FP PS 04 E - LOAD 400 kgLifter with manual pushing and lifting with electro-hydraulic pump, allows to lift loads (axis, bags, containers, minipallet, etc.) with maximum weight of 400 kg up to a height of 1510 mm. The elevator FP PS 04 E is compact and easy to handle. It is equipped with polyurethane wheels of large diameter for high smoothness (two fixed and two steerable complete with brake). It is supplied with loading forks with a length of 650 mm.The battery 12 V-80 Ah, maintenance-free, combined with the robust engine and control electronics with overload protection ensures safe and reliable operation. The battery charger is integrated.MODELMOD. FP PS 04 ECapacity loadKg. 400Min. height from floormm. 90Max. lifting heightmm. 1510Forks lengthmm. 650External forks widthmm. 550Single fork widthmm. 105Internal fork widthmm. 340Barycentermm. 325Lifting speedmm. 135 / sec.Descent speed12 sec.Battery12 V – 80 AhBuilt-in charger220 VLifting engine powerKw. 0.8Machine dimensionsmm. 580 x 1090 x 1730 h.Wheeled frame heightmm. 80 (can be inserted under the pallet)Fixed wheels diametermm. 75Steering wheels diametermm. 125WeightKg. 127Lifter with forks.The load must be evenly distributed on the forks.As with all lifting equipment, care must be taken to the security diagram.Depending on the size and characteristics of the elevator, with increasing height or distance from the center of gravity, the capacity decreases.Products are very robust and mechanically simple.It is rare that they have some problems. In the event, all the spare parts are in stock.All models are CE certified and are supplied with a specific manual for use and maintenance.For the use of the elevator, a specific driving license is not necessary.The operator must be trained and informed. It is necessary that the instructions in the manual are read and respected.OPTIONAL:• ACC-PZ Galvanized steel plan:Galvanized steel plan that can be inserted above the forks. Plan dimensions mm 580x650 - load 400 kg.• ACC-PN-VRP lowered V-platform for coils - parallel:Allows horizontal lifting and transport of reels with max. width 600 mm and weight max. of 100 Kg - parallel to the direction of advancement of the trolley.• ACC-PN-V1/2 V-platform for coils - parallel or perpendicular (at choice):Allows horizontal lifting and transport of reels with max. width 600 mm and weight max. of 150 Kg - parallel or perpendicular to the direction of advancement of the trolley.• ACC-APF1 Fixed reel holder shaft:Diameter 50 mm and length 600 mm, allows the gripping and horizontal transport of reels with max. width 600 mm and weight max. of 150 Kg. The fixed reel-holder shaft is not an interchangeable accessory with the others available (e.g. V-shaped platform for reels). By choosing the fixed reel-holder shaft, the elevator will be deprived of the two front forks and the metal plate.• ACC-APF2 Fixed reel shaft + elongated supports:Diameter 60 mm and length 1000 mm, allows the gripping and horizontal transport of reels with max. width 600 mm and weight max. of 100 Kg. The fixed reel shaft is not an accessory interchangeable with the others available (e.g. V-shaped platform for reels). By choosing the fixed reel shaft, the elevator will be deprived of the two front forks and the metal plate. This modification includes the lengthening of the front supports of the trolley for safe use.• ACC-PGN1 Pin with hook version 1:Pin with hook load 100 kg and maximum lifting height at the hook 1800 mm - maximum distance from the upright 600 mm. The pin with hook is not an accessory interchangeable with the others available (e.g. V-platform for reels). By choosing the pin with hook with a capacity of 100 kg, the lifter will be deprived of the two front forks and the metal surface.• ACC-PGN2 Pin with hook version 2:Pin with hook load 200 kg and maximum lifting height at the hook 1600 mm - maximum distance from the upright 450 mm. The pin with hook is not an accessory interchangeable with the others available (e.g. V-platform for reels). By choosing the pin with hook with a capacity of 200 kg, the lifter will be deprived of the two front forks and the metal surface.• Double fixed reel holder pinDouble fixed pin for reels with a maximum width of 600 mm. Ideal for lifting and loading reels inside machinery. Maximum capacity 80 kg. The double fixed pin is not an interchangeable accessory with the others available (e.g. V-shaped platform for reels). By choosing the double fixed pin, the lifter will be deprived of the two front forks and the metal surface.Models and features available: MOD1 (Elevator with loading forks - Capacity 400 kg - lifting height 1510 mm), MOD2 (Manual lifter with electrical lifting, capacity 400 kg up to 1510 mm)Optional accessories: Galvanized steel plan, V-platforms for reels, Fixed reel holder shafts, Pins with hooks, Double fixed reel holder pinTechnical Specifications:Model: FP PS 04 ECapacity: 400 kgMinimum height from floor: 90 mmMaximum lifting height: 1510 mmForks length: 650 mmExternal forks width: 550 mmSingle fork width: 105 mmInternal fork width: 340 mmBarycenter: 325 mmLifting speed: 135 mm/secDescent speed: 12 secBattery: 12 V – 80 AhBuilt-in charger: 220 VLifting engine power: 0.8 kWMachine dimensions: 580 x 1090 x 1730 mm (h)Wheeled frame height: 80 mm (can be inserted under the pallet)Fixed wheels diameter: 75 mmSteering wheels diameter: 125 mmWeight: 127 kg
