Mechanical workholding component TBU seriesstainless steelsmooth
Add to favorites
Compare this product
Characteristics
- Type
- mechanical
- Other characteristics
- smooth, stainless steel
Description
The replaceable ball swivels to allow for self-alignment on uneven surfaces. The flat cone design provides a large contact surface for greater force distribution. A Viton O-ring holds the ball in place while keeping contaminants out and providing smooth ball movement. The housing is made from alloy steel, heat treated to Rc 43/46 with a black oxide finish. The replaceable ball is made from 300 series stainless steel. Replacement balls and O-rings can be ordered separately.
Catalogs
Fixtureworks catalog
572 Pages
