Power factor panel meter A72PYanalogrecessed
Add to favorites
Compare this product
Characteristics
- Measured value
- power factor
- Display
- analog
- Type
- recessed
Description
Analogue Power-Factor meter, three-phase, 3 wires, 240° scale, 72x72
• rated burden (A) 0,5VA (range 5A)
• rated burden (V) 3VA (range 100V)
• input range 90÷110% Un
• continuous overload 1,2 Un; 1,2 In
• instantaneous overload 2 Un; 10 In
• accuracy 1,5%
• power supply /self-supplied
• overvoltage category CAT III 600V P.D. 2
• operating temperature -25 +50 °C
• storage temperature -40 +80 °C
• protection for housing IP52
• protection for terminals IP00
• manufactured according to CEI-DIN-VDE-IEC
