Bi-metal thermometer D31D100BP seriesgas expansiondial°C
Add to favorites
Compare this product
Characteristics
- Technology
- bi-metal, gas expansion
- Display
- dial
- Units of measurement
- °C, °F
- Protection level
- IP65
- Configuration
- flange
- Applications
- for industrial refrigeration, industrial, for food, for chemical products, HVAC, for the petrochemical industry, for flue gas, for harsh environments, machine, for hot water, for flame-heated furnaces, sanitary, for harsh environments, for exhaust gas
- Other characteristics
- stainless steel, glass, with temperature probe, high-temperature, rugged
- Temperature
Max.: 650 °C
(1,202 °F)Min.: 0 °C
(32 °F)- Precision
1.6 %
- Dial diameter
100 mm
(3.9 in)
Description
Suitable for corrosive media and environments in chemical process, petroleum and food industry.
Inert gas expansion thermometers with "Bourdon" elastic element and room temperature compensator by bimetallic strip.
Manufactured in accordance with standard EN 13190. Capillary tube case inlet radial or back, installation by means of a panel ring or triangular flange.
They are reliable instruments that withstand extreme working conditions: engine vibrations, humidity and aggressive media such as seawater.
Specially designed to measure temperatures remotely in the chemical, petroleum or food industries.
Specifications
Sensor: Gas expansion
Closing of the case: Bayonet
Case material: Stainless steel AISI 304
Mounting: Radial connection with back flange
Scale: Celsius/Fahrenheit
Inner components material: Copper alloy
Stem diameter: Ø10mm
Stem material: Stainless steel AISI 304
Capillary covering material: Stainless steel AISI 304
Logo: Gesa
