Electrical cable cutting and stripping machine GM35

blade

The CUTTING AND STRIPPING MACHINE GM35 is an electronic and latest generation machine for CUTTING and STRIPPING UNIPOLAR CABLES up to 35 mm2 and MULTI-POLE CABLES up to 15 mm in external diameter. One of the peculiarities of this CUTTING AND STRIPPING MACHINE GM35 lies in the opening of the rollers (pneumatically) at the output of the CABLE during the head STRIPPING phase allows the CUTTING AND STRIPPING MACHINE GM35 to make UNLIMITED OUTER STRIPPING with extreme precision and simplicity. In addition, the CUTTING AND STRIPPING MACHINE GM35 gives you the possibility to: CUTTING AND STRIPPING UNIPOLAR CABLES with stranded and rigid conductors up to 35 mm2 CUT AND STRIP MULTIPOLAR CABLES up to 15 mm in diameter Perform COMPLETE STRIP - SEMI STRIP - INTERMEDIATE STRIP The CUTTING AND STRIPPING MACHINE GM35 is supplied complete with all accessories, protections, the instruction manual and CE certifications. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - 6 bar ABSORBIMENT - 800 W STRIPPING LENGTH - Front 1÷150 mm – Back 1÷150 mm WORKABLE SECTIONS - 0,1÷35 mm² CUTTING LENGTH - 1 mm÷100 m FEEDING - 8 Drive Motors WORKABLE CABLE - PVC-Teflon-Silicon-Glass PRODUCTIVITY - L = 100 mm, 3.000 – 5.000 pcs/h TOLERANCE - ≤ 0.002xL (L= Cutting Length) DISPLAY - Display LCD Liquid Cristal Display MEMORY - 99 Programs WEIGHT - 40 Kg DIMENSIONS - 420x515x345 mm (WxDxH) IN ADDITION TO THE SALE OF THE EQUIPMENT GM AUTOMAZIONI IS ABLE TO PROVIDE MANY SERVICES, INCLUDING: WIDE RANGE OF PRODUCTS FROM OUR PRODUCTION AND THE BEST BRANDS ON THE MARKET DESIGN AND REALIZATION OF SPECIAL SYSTEMS
