Cable cutting and stripping machine D16

bladewith touch screenautomatic

The CUTTING AND STRIPPING MACHINE GM D16 is suitable for automatic machining of UNIPOLAR CABLES from 0,1 to 16 mm² section and MULTIPOLAR CABLES with a maximum diameter 11 mm. The CUTTING AND STRIPPING MACHINE GM D16 has an electrical operation with totally electronic setting of all machining parameters. Fully english software with quick touch-screen setting for all jobs with the ability to store up to 99 programs. The CUTTING AND STRIPPING MACHINE GM D16 is CE-compliant and comes complete with all accessories, protections and instruction manuals. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - No ABSORBIMENT - 700 W STRIPPING LENGTH - Front 0,1÷80 mm – Back 0,1÷50 mm WORKABLE SECTIONS - 0,1÷16 mm² - Till to 11 mm CUTTING LENGTH - 1 mm÷100 m FEEDING - 4 Drive Motors WORKABLE CABLE - PVC-Teflon-Silicon-Glass PRODUCTIVITY - L = 100 mm, 3.000 – 8.000 pcs/h TOLERANCE - ≤ 0.002xL (L= Cutting Length) DISPLAY - Display LCD Liquid Cristal Display MEMORY - 99 Programs WEIGHT - 95 Kg DIMENSIONS - 700x500x430 mm (WxDxH)
