Cable cutting and stripping machine GM150 M

with touch screenelectric

The CUTTING AND STRIPPING MACHINE GM150 M is a electronic CUTTING and STRIPPING UNIT suitable for the processing of the majority of CABLES on the market (PVC, Teflon, silicone, glass etc.). The CUTTING AND STRIPPING MACHINE GM150 M has an electric operation with electronic setting of all parameters in a simple and fast, ability to set the processing programs which are stored even after switching off the CUTTING AND STRIPPING MACHINE GM150 M and you can insert the input data via touch-screen. The CUTTING AND STRIPPING MACHINE GM150 M is complete with CE certification. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - 6 Bar ABSORBIMENT - 2000 W STRIPPING LENGTH - Front 1÷ 300 mm – Back 1÷150 mm WORKABLE SECTIONS - 6÷150 mm² / Wire guide passage 35 mm CUTTING LENGTH - 20 mm÷100 meters FEEDING - 4 Belt Feeding WORKABLE CABLE - PVC-Teflon-Silicon-Glass PRODUCTIVITY - L = 100 mm, 600 - 800 pcs/h TOLERANCE - ≤ 0.002xL (L= Cutting Length) DISPLAY - Display LCD Liquid Cristal Display MEMORY - 99 Programs WEIGHT - 240 Kg DIMENSIONS - 1350x7000x12000 mm (WxDxH)
