Electrical cable cutting and stripping machine GM2,5

bladeelectricautomatic

The CUTTING AND STRIPPING MACHINE GM2,5 is a completely electronic machine and is suitable for the automatic processing of unipolar wires up to 2,5 mm2 of section. The CUTTING AND STRIPPING MACHINE GM2,5 has an electric operation with totally electronic setting of all the processing parameters. With the CUTTING AND STRIPPING MACHINE GM2,5 you have the possibility to memorize up to 99 programs, quick setting of all the processes using the LCD-display. The CUTTING AND STRIPPING MACHINE GM2,5 is supplied complete with all accessories, the instruction manual and complete with CE certifications. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - No ABSORBIMENT - 300 W STRIPPING LENGTH - Front 1÷30 mm – Back 1÷15 mm WORKABLE SECTIONS - 0,05÷2,5 mm² CUTTING LENGTH - 1 mm÷100 m FEEDING - 2 Drive Motors WORKABLE CABLE - PVC-Teflon-Silicon-Glass PRODUCTIVITY - L = 100 mm, 4.000 – 5.000 pcs/h TOLERANCE - ≤ 0.002xL (L= Cutting Length) DISPLAY - Display LCD Liquid Cristal Display MEMORY - 99 Programs WEIGHT - 30 Kg DIMENSIONS - 360x288x200 mm (WxDxH)
