Electrical cable cutting and stripping machine GM50 S

bladeelectricautomatic

The CUTTING AND STRIPPING MACHINE GM50 S is suitable for automatic machining of CABLES with a sections up to 50 mm2. The CUTTING AND STRIPPING MACHINE GM50 S has an electrical operation with totally electronic setting of all parameters, and used for the processing of electric cables this machine is optimal. The CUTTING AND STRIPPING MACHINE GM50 S has the possibility to memorize up to 99 programs with rapid setting by LCD display of all the processes. By saving the program in memory, it can be recalled to the next use. Thanks to this machine it is possible CUT and STRIP the electric wire with very high precision and with an unparalleled execution speed. Furthermore, this stripping and cutting unit gives you the possibility of: REMOVING SINGLE CORE CABLES with braided and rigid conductors Perform COMPLETE STRIPPING - SEMI STRIPPING - INTERMEDIATE STRIPPING The CUTTING AND STRIPPING MACHINE GM50 S is complete with CE certification. ALIMENTATION - Monophase 230 V 50/60 Hz PNEUMATIC ALIMENTATION - 6 Bar ABSORBIMENT - 1000 W STRIPPING LENGTH - Front 1÷150 mm – Back 1÷150 mm WORKABLE SECTIONS - 2÷50 mm² CUTTING LENGTH - 1 mm÷100 m FEEDING - 4 Belt Feeding-8 Drive Motors WORKABLE CABLE - PVC-Teflon-Silicon-Glass PRODUCTIVITY - L = 100 mm, 2.000 – 5.000 pcs/h TOLERANCE - ≤ 0.002xL (L= Cutting Length) DISPLAY - Display LCD Liquid Cristal Display MEMORY - 99 Programs WEIGHT - 85 Kg DIMENSIONS - 420x515x345 mm (WxDxH) IN ADDITION TO THE SALE OF THE EQUIPMENT GM AUTOMAZIONI IS ABLE TO PROVIDE MANY SERVICES, INCLUDING: WIDE RANGE OF PRODUCTS FROM OUR PRODUCTION AND THE BEST BRANDS ON THE MARKET
