Life cycle testing machine 8022-HD

automatedcomputer-controlledfor cigarettes

Product Description
This bench-top tester is designed to position vape/e-cigarette devices into dedicated test fixtures and perform button life-cycle simulation under configurable load, speed, stroke and cycle counts. It reproduces repeated key actuations to validate mechanical and electrical endurance of the product.

Product Advantages

• Manufacturing expertise — engineered for repeatable, controlled fatigue testing with industrial-grade components.
• Customizable test parameters — interchangeable weight sets and adjustable fixtures to match device geometries.
• On-site QC process — AQL inspection and production quality oversight available.
• Adjustable profiles — speed, stroke and cycle limits configurable to replicate a range of use conditions.

Product Specifications

• Model: 8022-HD
• Stations: 4 (simultaneous operation)
• Weight load options: 10 g / 20 g / 50 g / 100 g / 200 g (4 sets each; customizable)
• Cycle counter range: 0–99,999,999 (presettable)
• Conduction counter: 0–999,999 cycles (automatic counting; stops on disconnection)
• Test speed: 5–60 cycles/min (knob-adjustable)
• Stroke range: 0–60 mm (manual adjustment)
• Fixture clamping range: 60 × 70 mm (manual adjustment)
• Power supply: AC 220 V
• Dimensions (L×W×H): 500 × 400 × 550 mm
• Net weight: 40 kg
