Fully-automatic bottling line FL series

for beer bottlesmanual loadingfor beverage industry

Overview
Foodline beer bottling machines automatically rinse, fill and cap bottles while preserving carbonation and minimizing foam. Available in manual, semi-automatic and fully automatic configurations, these lines suit microbreweries, craft and commercial breweries requiring bottle handling for glass and PET containers.

Technical Parameters of beer bottling equipment
Model | FL12-6 | FL18-6 | FL24-6 | FL32-8 | FL40-10 | FL50-12 | FL60-15
Filling Heads | 12 | 18 | 24 | 32 | 40 | 50 | 60
Capping Heads | 6 | 6 | 6 | 8 | 10 | 12 | 15
Output (bottles/hour) | 2,000 | 3,500 | 5,000 | 8,000 | 12,000 | 16,000 | 20,000
Power (kW) | 2.2 | 3.5 | 4.5 | 6 | 7.5 | 9.5 | 11.2
Dimensions (m) | 2.4×1.6×2.5 | 2.6×1.92×2.55 | 3.1×2.3×2.8 | 3.8×2.5×2.9 | 4.6×2.8×2.9 | 5.45×3.3×2.9 | 6.5×4.5×2.9
Weight (kg) | 2,500 | 3,500 | 4,500 | 5,600 | 8,500 | 9,800 | 12,800

Types of Beer Bottling Machines
Type | Best For | Output | Automation Level
Manual Beer Bottling Machine | Small batches, home brewers | 100–200 bottles/hour | Low
Semi-Automatic Beer Bottling Machine | Craft breweries | 300–800 bottles/hour | Medium
Automatic Beer Bottling Machine | Medium to large-scale production | 1,000–5,000+ bottles/hour | High

How Does a Beer Bottling Machine Work?

• Rinsing: Internal cleaning of bottles using water or inert gas before filling.
• Filling: Pressure or counter-pressure filling to maintain carbonation and reduce foam.
• Capping: Immediate sealing after filling to protect product quality.
• Labeling (optional): Integration with labelers or separate labeling modules.

Applications

• Glass and PET bottles
• Carbonated and non-carbonated beers
• Various bottle sizes (from 250 ml up to 1 L and more)
• Export-grade packaging and bottling lines

Manufacturer & Key Features
Foodline Machinery supplies modular bottling lines that can be configured by production capacity and container type. Typical attributes include PLC controls with user interface, modular station design for upgrades, compliance with sanitary requirements, and available after-sales technical support.

Specifications / technical details

• Models: FL12-6, FL18-6, FL24-6, FL32-8, FL40-10, FL50-12, FL60-15.
• Filling heads and capping heads listed per model above.
• Production range: 2,000–20,000 bottles/hour depending on model and bottle size.
• Power consumption: 2.2–11.2 kW typical per model.
• Machine stages: rinsing, pressure or counter-pressure filling, immediate capping; optional labeling integration.
• Suitable for glass and PET containers and carbonated beverages; supports multiple bottle sizes for export-ready packaging.
