DC reed relay RY
AC2NOC1NOC/NCC

DC reed relay
DC reed relay
Add to favorites
Compare this product


Characteristics

Control voltage
DC, AC
Contact configuration
2NOC, 1NOC/NCC
Features
miniature
Mounting
surface-mount, for printed circuit boards
Function
power
Other characteristics
monostable
Output voltage

Min.: 5 V

Max.: 240 V

Switching current

10 A, 16 A

Description

2 NOC or 1 NOC+1 NCC max. 16 A switching & permanent current Drive available as monostable DC or AC Load disconnecting relay with 3 mm contact gap Ambient temperature -25 to +55 °C cULus approval (version with 2 NOC) Solder legs or 6.3 mm flat plug connections Attachment to 35 mm DIN rail possible The HENGSTLER RY mains isolation relay is predominantly used in appliances for which two-pole disconnection is prescribed. The two contacts in this relay open by a defined amount of > 3 mm. The creepage and clearance distances between the contacts and the drive system are > 8 mm. The RY mains isolation relay can be supplied with either a DC or an AC monostable drive system.
