Solid milling cutter GH-K series
deburringHSSfor cast iron

solid milling cutter
solid milling cutter
solid milling cutter
solid milling cutter
solid milling cutter
solid milling cutter
solid milling cutter
solid milling cutter
Add to favorites
Compare this product


Characteristics

Construction
solid
Type
deburring
Material
HSS
Treated material
for cast iron, for stainless steel, for hardened steel, for titanium alloys, for brass, for aluminum alloys, for carbide
Other characteristics
high-performance, cutting edge, high-precision, high-speed, with cylindrical shank, conical, for chamfers
Diameter

3 mm, 4 mm, 9 mm, 25 mm, 45 mm
(0.12 in, 0.16 in, 0.35 in, 0.98 in, 1.77 in)

Description

The range consists of two types: a countersinking tool with three cutting edges and a countersinking tool with only one cutting edge. Each design is available in two versions with a countersink diameter range from 3.0 – 25.0 mm and another from 4.0 – 45.0 mm. The HEULE countersinking tools are available with countersinking angles of 60° and 90°. Construction The GH-K has an alloy heat-treated steel tool body and integrated internal coolant. The blades are made of coated carbide and can be resharpened or replaced. These cutting edges extend almost to the countersinking tool tip, providing a wide countersink diameter range. Process steps description The HEULE countersinking tool enables chatter-free countersinking and circular milling. The tool's internal coolant supply delivers the coolant directly to the cutting edge. The three carbide cutting edges and three insert seats in the tool body are manufactured to extremely tight tolerances. This means that high cutting parameters allow for the optimal production of chatter-free countersinks on the bores and chamfers on the edges of workpieces. Three interchangeable, precisely matched carbide blades Internal cooling available Circular milling possible
