Ultrasonic level sensor UE3006 for water4-20 mAfor storage tanks
Add to favorites
Compare this product
Characteristics
- Technology
- ultrasonic
- Medium
- for water
- Interface
- 4-20 mA
- Applications
- for storage tanks, for the food industry
- Other characteristics
- smart, IP67, IP68, IP66, IP65
- Level range
Max.: 2 m
(6'06" )Min.: 0 m
(0'00" )- Process temperature
Max.: 60 °C
(140 °F)Min.: -20 °C
(-4 °F)
Description
UE3006 ultrasonic water level sensor combines ultrasonic sensors, temperature sensors, ultrasonic servo circuit, transmission circuit and uses SMD components and ASIC. All these features realize a concise and smart level transmitter.
Application :
● Non contact distance level measurement
● Food level monitoring
● Industrial fuel level measurement
● Tank level measurement
Advantages
01
Support M49*1.5 mm threaded into type installation and coil clamping type installation
02
Less than 9°C Beam angle design ,less than 200ms responsible time to make sure more accuracy
03
Housing adopts the NLEPE synthetic material IP66 waterproof
04
High quality terminal blocks ,Excellent anti-jamming is strong, long term stability
VIDEO
Catalogs
UE3006
4 Pages
