Emergency intercom KNZD-70
audiovideoaccess control

emergency intercom
emergency intercom
emergency intercom
emergency intercom
emergency intercom
emergency intercom
Add to favorites
Compare this product


audio, video
emergency, access control, for elevators, for bank, passenger Help Point
Protection level
with numeric keypad, rugged, vandal-proof, waterproof, scratch resistance, security, secure, robust, corrosion-resistant, IP65, weather-proof, IK 10, IP66
Other characteristics
with color screen, IP


The passenger assistance intercom will be designed to work on apartment, hospital, school, metro…Housed in robust metal body, vandal resistant and tamper-resistant. Assistance intercom ensure voice loud and clear. Good looking, durable, easy to install, comfortable buttons, and low power consumption. DESCRIPTION ITEM Unit main features 1.VOIP Telephone BI-Directional Video telephone Scratch resistant, HD Screen 2.SIP supports 5 SIP servers SIP 2.0 Support TR069 3.7" digital TFT-LCD of 1024 x 600 pixels with Visual angle adjustable display screen 4.sensor camera with 5Mega pixels 2xLAN, PoE, USB 5.TWO group of speed dial for emergency call. Protection: About IP65 6.Speaker: 8 ohm 1.5W, loudness 85dB(A) to 65dB(A) MIC’s working distance 80cm 7.Ring: >95dB. Coverage 1.5m radius 8.The call button is flash when ring, lighting during a call, off when standby. 9.With induction loop coverage 1M radius. Metal body 10Braille words for disable. 11.HD voice with high quality headset/HD voice in speakerphone mode Camera Specification 1.Array size::2592 x 1944 2.Lens size: 1/4” 3.Lens chief ray angle: 24 4.Input clock frequency: 6~27 MHz 5.Maximum Image transfer rate: 6.QSXGA (2592 X 1944): 15fps 7.720P 8.Sensitivity: 600 mV/lux-sec 9.Shutter: rolling shutter/frame exposure 10.Maximum exposure interval: 1964 xTROW 11.Pixel size: 1.4 um X 1.4 um 12.Dark Current: 8 mV/s @ 60℃ junction temperature 13.Image area:3673.6 um X 2738.4 um 14.viewing angle: 187°
