Automatic welding machine

for pipessleevefor stainless steel

Description
Automatic inner prop welding machine for circular welding of base plate to pipe and for welding pipe to threaded sleeve from the inside or top side. Designed for continuous, high‑production operation and typically used together with outer prop welding units to assemble complete prop structures.

Tags

• Outer Prop Welding Machine
• Inner Prop Welding Machine
• Welding Machine
• Automatic Inner prop welding machine
• Stainless Steel Inner Prop Welding Machine
• Inner Prop Welding Machine Exporters India

Available Options

• Maximum length required (input field)
• Min and max diameter of the job (input field)
• Expected price (input field)
• Purchase timeframe: Immediately; Within a week; Within 15 days; Within a month; Others; Don't know exactly

Product details
This system performs circular welding of base plate to pipe and of pipe to threaded sleeve either from the top side or from inside the sleeve, enabling fast, uniform welds and protecting the operator from burns during continuous welding cycles. The unit typically operates on 380–415 V 50/60 Hz AC and is controlled by a Siemens PLC with AC inverter motor drive. Clamping and de-clamping of the job are pneumatically operated for movement of the welding torches.

Specifications

• Electric supply: 380–415 V 50/60 Hz AC (alternative: Single Phase 220 V 50/60 Hz)
• Speed: 2 to 10 RPM
• Motor drive: AC inverter type
• Motor: AC 3-phase 220 V
• Torch clamping: Pneumatic
• Length adjustment: 150 to 2400 mm
• Dimensions (L x W x H): 11.3 x 2.5 x 5.3 ft

Key features

• Circular welding on base plate with pipe and on pipe with threaded sleeve (top side or inside sleeve)
• Engineered for high production and uniform weld quality while reducing operator burn risk during continuous operation
• Siemens PLC control
• AC inverter motor drive
• Pneumatically operated torch clamping and de-clamping
• Adjustable speed and length to accommodate a range of job sizes
