Automatic welding machine

220V single phasevariable-speedsingle-phase

Overview
Automatic base jack welding machine for welding base plates to solid and hollow jacks and threaded bars without additional tack welding. Engineered for industrial production to provide high throughput and consistent weld quality. Compatible with Cuplock and Ringlock scaffold components.

Detailed description
The machine welds solid jacks, tie rods and hollow jacks to base plates and U-bases of various shapes. Adjustable length range 300 mm to 1000 mm and suitable diameters 28 mm to 48 mm. Length adjustment via screw drive; built-in compensation for part ovality. Production capability up to 1200 pieces per 10-hour shift. Eliminates need for pre‑tacking pipe or rod to the base.

Available options / input fields on product page

• Maximum length required (user input)
• Minimum and maximum diameter of the job (user input)
• Expected price (user input)
• Purchase timing (Select: Immediately / Within a week / Within 15 days / Within a month / Others / Don't know exactly)

Specifications (page table)
Electric supply: Single Phase 220 ±10% V, 50/60 Hz
Speed: 2 to 10 RPM
Motor drive: 75 C
Motor type: DC
Torch clamping: Pneumatic
Length adjustment: Up to 1000 mm
Dimension (L x W x H): 5.4 x 2.5 x 4.7 ft

Tags

• Base Jack Welding Machine
• Automatic Base Jack Welding Machine Manufacturer
• Base Jack Welding Machine Manufacturer
• Industrial machinery
• Industrial machinery Manufacturer in India
• Machinery Exporter in India
• Welding Machine

Technical specifications

• Electric supply: Single Phase 220 ±10% V, 50/60 Hz
• Operating speed: 2 to 10 RPM
• Motor drive rating: 75 C
• Motor type: DC
• Torch clamping: Pneumatic
• Length adjustment: Up to 1000 mm (screw drive)
• Suitable job lengths: 300 mm to 1000 mm
• Suitable diameters: 28 mm to 48 mm
• Production capability: up to 1200 pieces per 10-hour shift
• Footprint (L x W x H): 5.4 x 2.5 x 4.7 ft
