T-shaped tube connector TE series

crossstainless steeladjustable

Cross clamps TE of matt blasted precision-cast stainless steel have a slitted clamping point machined by cutting methods. The bores at the clamping points are situated in a plane and arranged in a T-shape. They receive typically available construction tubes with full surface contact over the entire cross-section of the bore. At the screw points, carriage bolts together with cap nuts or adjustable hand levers reduce the bore cross-section for clamping. Type B is equipped with seals at the screw points. Adjustable hand levers are intended for repeated, tool-free clamping. Under the designation HEK, these are available separately for individual use and in other designs. Compared with the tool-operated hex socket cap screw, the clamping force achievable with an adjustable hand lever is lower due to the shorter lever length. On request Screw points with hex head screws or mixed screw / adjustable hand lever elements
