Water pump Dostec 50electricdiaphragmstationary
Add to favorites
Compare this product
Characteristics
- Fluid
- water
- Operation
- electric
- Technology
- diaphragm
- Mobility
- stationary
- Domain
- chemical
- Applications
- metering, service, injection, high-precision
- Material
- PTFE
- Voltage
- 400 V, 230 V
- Other characteristics
- adjustable
- Flow
Min.: 100 l/h
(26.41721 us gal/h)Max.: 1,200 l/h
(317.00646 us gal/h)- Pressure
Min.: 4 bar
(58.015 psi)Max.: 12 bar
(174.045 psi)- Power
0.75 kW
(1.02 hp)- Length
392 mm, 415 mm
(15 in, 16 in)- Width
204 mm, 214 mm, 224 mm
(8.03 in, 8.43 in, 8.82 in)- Height
440 mm, 460 mm
(17.32 in, 18.11 in)- Weight
21 kg
(46.3 lb)
Description
DOSTEC 50 dosing pumps are heavy duty, high precission, piston pumps for dosing liquid products.
This series allows many injection possibilities depending on the head being chosen. The available heads are from 330 to 1200 l/h for the piston series, and from 207 to 1080 l/h for the diaphragm series.
DOSTEC 50 dosing pumps are manufactured with materials that can resist most chemicals products, even acids. They are designed for all sorts of processes where it is necessary to dose a product into a hydraulic network, such as: food, textile, chemical industry, water treatments, etc. (See materials in Technical Features). In case there is any doubt about compatibility of materials with the products to be used please contact ITC S.L. Technical Service.
Dosing flow of each module is adjustable independently with no need to stop the pump from 0% to 100% of its capacity.
