Single-phase electric energy meter EM124043

DIN railRS-485pulse output

The EM124043 is a single-phase two-wire STS compliant prepayment meter with an integrated keypad for secure credit management. Operating at 230V with a current range of 10(80)A, this Class 1 accuracy meter provides a pulse output of 1000 imp/kWh. Equipped with both IR and RS485 communication interfaces (IEC1107 protocol), this meter is designed for use with a separate Customer Interface Unit (CIU), model X129013-01. It features a bypass connection type and is suitable for hanging installation. Brief introduction The EM124043 is a single-phase two-wire STS compliant prepayment meter with an integrated keypad for secure credit management. Operating at 230V with a current range of 10(80)A, this Class 1 accuracy meter provides a pulse output of 1000 imp/kWh. Equipped with both IR and RS485 communication interfaces (IEC1107 protocol), this meter is designed for use with a separate Customer Interface Unit (CIU), model X129013-01. It features a bypass connection type and is suitable for hanging installation. Function description Accuracy Class 1 Pulse Output: 1000 imp/kWh Designed for use with CIU (X129013-01) Bypass Connection Hanging Installation Technical Parameters mpulse Constant 1000imp/kWh Starting Current 20mA Accuracy Cl.1 LCD LCD6+2=999999.99kW Power Consumption <10VA/2W Operation Temp. -20~55℃ Maximum Humidity 95% Standard IEC62052-11, IEC62053-21, IEC62056-21, IEC62055-41, IEC62055-51 Protection Degree IP54
