Internal parts: stainless steel
Seals: NBR, EPDM, FPM, PTFE
Fluid temperature: -10°C to +90°C (NBR); +130°C (EPDM, FPM, PTFE)
Ambient temperature: +55°C max
Viscosity: 21 mm2/s max.
Response time: 10 to 20 ms
Voltage: 230, 115, 48, 24 V AC / 24, 12 V DC
Duty cycle: continuous (ED100%)
Cycling rate: 1000 cycles/min max
Electrical protection: IP65 (with plug to ISO 6952 / ISO 4400)
Long term use in humid environment requires the use of sealing sets.
