Compensation thermocouple wire M27H-64P-L1450

wiring loom

Description
This multipoint thermocouple cable is a 27-point multichannel harness (nominal length 1.45 m) designed to group and extend thermocouple signals in industrial installations. It integrates a 64-pin fixed-face connector to consolidate all measurement points into a single connection, simplifying wiring and installation near reading or control equipment.

Key features

• Number of points: 27 measurement points
• Length: 1.45 m (1,450 mm)
• Connector: 64-pin fixed-face connector
• Type: Multipoint/multichannel thermocouple cable
• Function: Signal grouping and extension
• Recommended use: Industrial installations and machinery

Additional information (table)
Weight: 8 kg
Dimensions: 50 × 50 × 30 cm

Connection and use
The cable routes signals from a 27-point thermocouple assembly to reading, control or data acquisition equipment. Each point remains an independent channel while all channels are gathered into one harness terminating in a 64-pin connector, reducing the number of separate cables and facilitating identification and connection of temperature points.

Other product names

• Multipoint thermocouple harness
• Multipair compensation cable
• Multipair thermocouple cable
• Multipoint compensation cable
• Thermocouple multipoint hose
• Multichannel thermocouple cable

Advantages of the 1.45 m length

• Avoids installing longer cable than necessary
• Facilitates assembly in confined spaces
• Groups 27-point connections
• Reduces the number of independent cables
• Allows a common connection via a 64-pin connector
• Keeps wiring neater

Industrial applications

• Industrial machinery
• Furnaces and thermal processes
• Equipment with multiple temperature points
• Test and control systems
• Production plants
• Temperature reading and recording equipment
• Repair and maintenance work

Data required to verify compatibility

• Thermocouple type required (K, J, T, N, S, R, etc.)
• Number of measurement points
• Required cable length
• 64-pin pinout / pin assignment
• Connector type and model
• Operating temperature range
• Installation conditions (humidity, chemicals, mechanical stresses)
• Interface of the reading or control equipment

Technical characteristics / specifications

• SKU (code): M27H-64P-L1450
• Number of points: 27
• Nominal length: 1.45 m (1,450 mm)
• Connector: 64 pins, fixed-face
• Weight: 8 kg
• Dimensions (packaging estimate): 50 × 50 × 30 cm
• Origin: Made in Spain
• Product type: Multipoint/multichannel thermocouple cable for grouping and extending signals
