Wiring loom thermocouple wire ALTK-10C-L17-T8

for validationfor autoclave validationfor temperature mapping

Description
K-type multichannel hose prepared for K thermocouples with 10 separate channels, designed to connect multiple temperature points in autoclaves and industrial thermal equipment. Each channel carries the signal from a K thermocouple to the control or data-logging system and bundles the wiring into a single assembly to keep connections organized.

K-type multichannel hose for autoclaves
Allows routing signals from ten K thermocouples to a control system during the same cycle, simplifying wiring inspection and identification of each measurement point.

Main features

• Prepared for K-type thermocouples.
• 10 separate temperature channels (one per measurement point).
• Bundles wiring into a single hose to keep connections tidy and organized.
• Channels marked to facilitate inspection and connection identification.
• Intended for autoclaves and industrial thermal equipment.

Typical applications

• Measuring different zones inside an autoclave during a cycle.
• Temperature control of parts, molds or multiple loads.
• Recording heating and cooling cycles.
• Monitoring thermal curing processes.
• Replacement or installation in systems requiring multiple K-type thermocouples.

What to check before buying

• That sensors and equipment connectors are K-type thermocouples.
• The number of channels required by the system (this product has 10 channels).
• Total hose length and the length of each section required.
• Connector types and compatibility with autoclave connections.
• Maximum operating temperature and the pressure/operating environment where the hose will be installed.

Frequently asked questions

• How many channels does this hose have? The hose has 10 separate channels and can carry signals from ten temperature points.
• Can it be used with J-type thermocouples? No. This hose is prepared for K-type thermocouples; for J-type sensors choose a hose specific for type J.
• What does the number of channels mean? The number of channels indicates how many signals the hose can carry; each channel corresponds to a different temperature point.
• Can it be used in an industrial autoclave? Yes, it is designed for measuring multiple points in autoclaves, but check temperature, length and connectors before installation.

Technical characteristics / specifications

• Weight: 5 kg
• Package dimensions: 50 × 50 × 30 cm
• Code / reference: ALTK-10C-L17-T8
• Manufactured in Spain by Jemar Termometria SL
• Prepared for K-type thermocouples
• Number of channels: 10
• Commercial status: Made to order
