Power take-off with clutch plate 59000 Double

high-torquefor heavy-duty applications

Overview
John Deere pump drives deliver modular, configurable power transmission solutions for pump applications. Designed for flexibility across engine types and mounting arrangements, the 59000 double pump drive supports dual pump outputs and high input power up to 522 kW (700 hp).

Key features

• 522 kW (700 hp) maximum power
• Modular design for multiple mounting options
• Engineered for quiet operation
• Dedicated OEM service and support

Benefits

• Perfect Fit — over 5,000 pump drive configurations using varied gear ratios, pump adapters and mounting options to match project specifications and simplify installation.

Modular Approach
Available in four series up to 708 kW (950 hp). Configurable as independent-mount, direct-engine-mount, or clutch-driven units. Adapters are available for multiple engine housings and flywheel sizes to ensure compatibility.

Integration Support
Application experts assist with system integration from engine to pump drives, including powershift and HMD transmissions, planetary drives, and inboard planetary axles to optimize performance and reliability.

Gear Ratios

• 0.721:1
• 0.78:1
• 0.84:1
• 0.898:1
• 1:1
• 1.13:1
• 1.2:1

Technical specifications

• Maximum Power: 522 kW
• Maximum Input Torque: 1695 Nm
• Maximum Output Torque: 881 Nm
• Maximum Input/Output Speed: 3000 rpm
• Type: Double
• Approximate Dry Weight: 98–145 kg
• Pump Rotation: Anti-enginewise
• Nominal Clutch Size: 292.1 mm, 355.6 mm
• Oil Capacity: 2.96–7.28 L
• Oil Type: JDM J20C specification; MIL-L-2015C or API classification GL-5
• Maximum Input Power: 522 kW
• Maximum Output Power (Per Pump Pad): 268 kW
• Gear Centers: 203.2 mm
• Flywheel Covers: SAE 1, SAE 2, SAE 3
