Drive unit 59000 Four

Overview
John Deere pump drives provide design flexibility. The 59000 Four pump drive delivers 522 kW (700 hp) in a modular package able to operate as double, triple or four-pump setups for high-torque, low-noise industrial applications.

Key Features

• 522 kW (700 hp)
• Modular design
• Engineered for quiet operation
• Dedicated OEM service

Benefits

• Perfect Fit - Over 5,000 pump drive configurations using varied gear ratios, hydraulic pump adapters and mounting options to meet design specifications.
• Modular Approach - Available in four series up to 708 kW (950 hp); supports independent mount, direct-engine mount or clutch-driven units with adapters for multiple engine housings and flywheel sizes.
• Integration Support - Application experts assist integration from engine to pump drives, including powershift and HMD transmissions, planetary drives and inboard planetary axles.

General Pump Drive Data
Maximum Power: 522 kW
Maximum Input Torque: 1695 Nm
Maximum Output Torque: 881 Nm
Maximum Input/Output Speed: 3000 rpm
Type: Four
Approximate Dry Weight: 143-213 kg
Pump Rotation: Anti-enginewise
Nominal Clutch Size: 292.1 mm, 355.6 mm
Oil Capacity: 7 L
Oil Type: JDM J20C specification; MIL-L-2015C or API classification GL-5
Maximum Input Power: 522 kW
Maximum Output Power (Per Pump Pad): 268 kW
Flywheel Covers: SAE 1, SAE 2, SAE 3

Available Gear Ratios
59000 Four Wide: 0.721:1, 0.78:1, 0.84:1, 0.898:1, 1:1, 1.13:1, 1.2:1

Technical specifications

• Maximum Power: 522 kW (700 hp)
• Maximum Input Torque: 1695 Nm
• Maximum Output Torque: 881 Nm
• Maximum Input/Output Speed: 3000 rpm
• Type: Four (four-pump configuration)
• Approximate Dry Weight: 143-213 kg
• Pump Rotation: Anti-enginewise
• Nominal Clutch Size: 292.1 mm and 355.6 mm
• Oil Capacity: 7 L
• Oil Type: JDM J20C specification; MIL-L-2015C or API classification GL-5
• Maximum Input Power: 522 kW
• Maximum Output Power (Per Pump Pad): 268 kW
• Flywheel Covers: SAE 1, SAE 2, SAE 3
• Available Gear Ratios: 0.721:1, 0.78:1, 0.84:1, 0.898:1, 1:1, 1.13:1, 1.2:1
• Modular configurations available (double, triple, four pump setups) with a wide range of gear ratios, hydraulic pump adapters and mounting options
• Intended for quiet operation and engineered for high-torque, demanding applications
