OCXO oscillator O-60Cxxxx-LPN-LGS series
electronicsurface-mounthigh-stability

OCXO oscillator
OCXO oscillator
Add to favorites
Compare this product


Characteristics

Type
OCXO
Technology
electronic
Other characteristics
surface-mount, high-stability
Electrical characteristics
low phase noise, ultra-low G sensitivity
Frequency

10 MHz

Description

The OCXO 6000 series is an array of high stability quartz oscillators (XO) with 10MHz output signal. These units exhibit carrier phase noise at 1Hz with less than -110dBc/Hz, at 10Hz less than -140dBc/Hz as well as at 100Hz better than -160dBc/Hz. The Noise Floor at 10kHz carrier offset and larger is better than –170dBc/Hz for supply voltage of 12V and true sine wave output signal. In addition, they can be configured with special low-g sensitivity type with better than 1 x 10-9/g for all 3 axes.

Catalogs

No catalogs are available for this product.

See all of KVG Quartz Crystal Technology GmbH‘s catalogs
