Light fixture VARILED
LEDfor machine toolssurface-mounted

light fixture
light fixture
light fixture
light fixture
light fixture
light fixture
light fixture
light fixture
Add to favorites
Compare this product


light fixture
Illumination technology
for machine tools
Other characteristics
surface-mounted, waterproof, IP68

4 W, 8 W, 12 W


Flat, robust, IP68 The VARILED in the surface-mounted version is intended for the initial equipping or retrofitting of machine and plant lighting. The surface-mounted LED luminaire is very compact, flat and robust. The high protection class IP68 certifies its resistance to many media. Its advantage is homogeneous and glare-free illumination, in a strength not to be expected from such a compact luminaire. YOUR BENEFITS _Very bright _Homogeneous, glare-free illumination _Very flat and space-saving design _Suitable for CNC _Ideal for retrofitting AREAS OF APPLICATION _For workplaces with limited space _Metalworking _Machine tools _Injection moulding machines, extruders and blow moulding machines _Maintance THE TECHNOLOGY _High-performance LED equipment for daylight white 5200-5700K _Beam angle 120° and colour rendition Ra >85 _Milled aluminium base body, black anodised, extremely robust _Glare-free PUR coating and heat dissipation to the rear _Luminous flux, depending on version, from 280 lm to 1960 lm _For application in ambient temperatures from -10°C to +40°C _Heat dissipation to the rear – no burn-in of coolant _IP 68 degree of protection and above-average service life > 60,000h (L70/B10) _24V DC connection voltage and 3 m connection cable with M12 plug connector _Direct fastening with M5 screws on the housing or using optional holders _Maintenance-free, 36-month warranty _Produced in Germany
