Safety light curtain MLD520-R3L

multibeamthrough-beammuting

Multiple light beam safety device receiver Device type - Receiver Special version - Reflective element for laser alignment aid Functions - Configuration by means of wiring Contactor monitoring (EDM), selectable Start/restart interlock (RES), selectable Reflective element for laser alignment aid - Yes Integrated muting indicator - No Integrated status indicator - No Type - 4, IEC/EN 61496 SIL - 3, IEC 61508 SILCL - 3, IEC/EN 62061 Performance Level (PL) - e, EN ISO 13849-1 MTTFd - 204 years, EN ISO 13849-1 PFHD - 6.6E-09 per hour Mission time - 20 years, EN ISO 13849-1 Category - 4, EN ISO 13849 Number of beams - 3 Piece(s) Beam spacing - 400 mm Protective circuit - Overvoltage protection Short circuit protected Supply voltage UB - 24 V, DC, -20 ... 20 % Current consumption, max. - 150 mA, Without external load Fuse - External with max. 3 A Number of digital switching inputs - 3 Piece(s) Type - Digital switching input Switching voltage high, min. - 18.2 V Switching voltage low, max. - 2.5 V Switching voltage, type. - 23 V Voltage type - DC Switching current, max. - 5 mA Number of safety-related switching outputs (OSSDs) - 2 Piece(s) Number of digital switching outputs - 1 Piece(s) Type - Safety-related switching output OSSD Switching voltage high, min. - 18.2 V Switching voltage low, max. - 2.5 V Switching voltage, type. - 23 V Voltage type - DC Current load, max. - 380 mA Load inductivity - 2,200,000 µH Load capacity - 0.3 µF Residual current, max. - 0.2 mA Residual current, type. - 0.002 mA Voltage drop - 1 V Switching element - Transistor, PNP Switching element - Transistor, PNP Type - Digital switching output
