Safety light curtain SLE46C-40.K2/4P-M12

single-beamthrough-beam

Functions - Alignment indicator Diagnostic output Type - 2, IEC/EN 61496, in combination with a suitable test monitoring unit, e.g. MSI-TR1B, In combination with a suitable test monitoring unit, e.g. MSI-TR1B SIL - 1, IEC 61508, in combination with a suitable test monitoring unit, e.g. MSI-TR1B, In combination with a suitable test monitoring unit, e.g. MSI-TR1B SILCL - 1, IEC/EN 62061, in combination with a suitable test monitoring unit, e.g. MSI-TR1B, In combination with a suitable test monitoring unit, e.g. MSI-TR1B Performance Level (PL) - c, EN ISO 13849-1:2008, In combination with a suitable test monitoring unit, e.g. MSI-TR1B MTTFd - 400 years, EN ISO 13849-1 Mission time - 20 years, EN ISO 13849-1 Category - 2, EN ISO 13849:2008, In combination with a suitable test monitoring unit, e.g. MSI-TR1B Protective circuit - Polarity reversal protection Short circuit protected Supply voltage UB - 24 V, DC, -20 ... 20 %, Incl. residual ripple Residual ripple - 10 %, From UB Open-circuit current - 0 ... 15 mA Number of digital switching outputs - 2 Piece(s) Switching voltage high, min. - 22 V Switching voltage low, max. - 2 V Switching voltage, type. - 23 V Voltage type - DC Switching current, max. - 100 mA Switching voltage - high: ≥(UB-2V) low: ≤ 2 V Switching element - Transistor, PNP Switching principle - Dark switching Function - Diagnostic output Switching element - Transistor, PNP Switching principle - Light switching Function - Switching output
