Crawler crane TCC-1400

boomtelescopiclattice

Base Rating 127 mt @ 2.3 m Main Boom Six-Section Formed Boom Telescope System Pin & Latch SmartFly Attachment 3 m – 9.4 m – 16.7 m Maximum Tip Height 78.5 m Engine Make & Model Cummins QSL9 Tier 4 Final Horsepower 239 kW @ 1,800 rpm Maximum Line Pull / Maximum Line Speed 10 151 kg / 163.7 mpm Standard Upper Weights 25 854 kg Standard Lower Weights 11 339 kg Main Transport Load 42 456 kg Overflow Load 3-4 Key Features New fly pinning designed for limited ladder use and eliminates hammering pins Lightweight nylon head sheaves reduce overall machine weight and increase lift capacities Quick-reeve boom head with quick-reeve block allows rope to be easily reeved over boom head Hammerhead boom nose allows operator to work at high boom angles Greaseless wear pads Optional auxiliary sheave off main boom Pick and carry the whole chart List chart selections in LMI Transports complete in four or five loads Main unit transports at 93,600 lbs (42 456 kg) with side frames removed Three to four overflow loads under 44,500 lbs (20 185 kg) Four widespread hydraulic jacks for easy side frame assembly/disassembly 2 mph (3.2 kph) high-speed travel Fold-up catwalks
