Benchtop power supply LPS-65P65B3

DCsingle-outputadjustable

Brief Introduction
The LPS-65P65B3 is engineered for precision high-voltage applications, providing an adjustable output (0–65 kV / 1 mA) with very low ripple (≤0.1%). Dual analog/digital control allows local potentiometer adjustment and remote 0–10 Vdc control. Communications interfaces: RS-232 and RS-485. Temperature coefficient ≤25 ppm/°C. Integrated filament power supply (0–5.5 V / 0.3–3.5 A) with preheating function. Compact footprint: 127 × 73 × 269 mm. Suited for X-ray systems, industrial testing and scientific research.

Specifications
Input voltage: 24 Vdc ±10%
Input current: Max 8.0 A
Output voltage range: 0–65 kV
Output current: Max 1.0 mA
Output power: Max 65 W
Stability: <0.01%/hr after 0.5 hr; <0.02%/8 hrs
Temperature coefficient: ≤25 ppm/°C
Ripple voltage: 0.1% P-P of maximum output voltage
Voltage regulation (load): 0.01% (no load to rated load)
Voltage regulation (input): ±0.01% (input variation ±10%)
Current regulation (load): 0.01% (no load to rated load)
Current regulation (input): ±0.01% (input variation ±10%)
Dimensions (W×H×D): 73 × 127 × 269 mm
Weight: 3.5 kg

Technical features / specifications

• Model: LPS-65P65B3
• Output specs: 65 kV, 65 W
• Adjustable output: 0–65 kV, up to 1.0 mA
• Maximum output power: 65 W
• Filament power supply: 0–5.5 V, 0.3–3.5 A with preheating
• Control: Dual analog/digital; local potentiometer and remote 0–10 Vdc control
• Communication interfaces: RS-232, RS-485
• Stability: <0.01%/hr after 0.5 hr; <0.02%/8 hrs
• Temperature coefficient: ≤25 ppm/°C
• Ripple: 0.1% P-P
• Input voltage: 24 Vdc ±10%
• Input current: Max 8.0 A
• Regulation (voltage/current): 0.01% load; ±0.01% for ±10% input variation
• Dimensions (W×H×D): 73 × 127 × 269 mm
• Weight: 3.5 kg
