Benchtop power supply LPC-30P30B1

DCsingle-outputadjustable

Brief introduction
The LPC-30P30B1 is a high-voltage power supply designed for high-voltage experiments, electron-optical systems and X-ray equipment. It provides an adjustable output voltage from 0 to 30 kV, a maximum output current of 1.0 mA and maximum output power of 30 W. Remote control interfaces include RS-232, RS-485 and USB. Integrated protection functions and status indicators support reliable operation. The unit can be customized to meet application-specific high-voltage requirements.

Applications

• Laboratory material analysis
• Nondestructive testing (NDT) inspection
• Integrated circuit (IC) inspection
• Electron optics and vacuum equipment
• Scientific research and high-voltage experiments

Key specifications

• Model: LPC-30P30B1
• Input voltage: 220 Vdc ± 10%
• Input current: Max 30 A
• Output voltage range: 0–30 kV
• Output current: Max 1.0 mA
• Output power: Max 30 W
• Stability: ≤0.01%/hr after 0.5 hr warm-up; <0.02% over 8 hrs
• Temperature coefficient: ≤25 ppm/°C
• Ripple (P-P): 0.1% of maximum output voltage
• Voltage load regulation: 0.01% (no load to rated load)
• Voltage input regulation: ±0.01% (input variation ±10%)
• Current load regulation: 0.01% (no load to rated load)
• Current input regulation: ±0.01% (input variation ±10%)
• Dimensions: 95 × 354 × 482 mm
• Weight: 4 kg

Performance and control
The supply offers high long-term stability, low ripple and precise regulation for voltage and current. Remote monitoring and control are available via RS-232, RS-485 and USB interfaces, enabling integration with test benches and automation systems.

Customization and ordering
Customized output ranges, connector options and control firmware can be provided on request. Provide application details to define required configurations and options.
