Commercial tent

transportabledisassemblablefor sports centers

General Details
The Polygon High Peak Tent is based on hexagon, octagon, decagon and dodecagon geometries. The high peak roof gives a distinctive architectural appearance and expands interior volume. A full range of compatible accessories is available: clear windows, ground anchors, base plate system, roof lining and inner curtains, glass walls and doors, ABS walls, transparent roof covers and sidewalls, flooring systems and rain gutters.

Performance and Applications
The tent features a stable structural design and can resist wind speeds up to 100 km/h (0.5 kN/m²). Assembly, disassembly and storage are user-friendly, allowing efficient on-site handling. Typical applications include events, parties, weddings, exhibitions and sports activities.

Product Specification
Span Width | Eave Height | Ridge Height | Bay Distance | Main Profile
6m | 2.6m | 5.18m | 3m | 100x48x3mm (4 - channel)
8m | 2.6m | 5.66m | 4m | 100x48x3mm (4 - channel)
9m | 2.6m | 5.83m | 4.5m | 100x48x3mm (4 - channel)
10m | 2.6m | 6.0m | 5.3m | 100x48x3mm (4 - channel)

Technical Features / Specifications

• Base configurations: hexagon, octagon, decagon, dodecagon
• Roof style: high peak (distinctive appearance, increased internal height)
• Wind resistance: up to 100 km/h (0.5 kN/m²)
• Assembly: user-friendly assembly, disassembly and compact storage
• Compatible accessories: clear PVC windows, ground anchors, base plate systems, roof lining and inner curtains, glass walls and doors, ABS rigid walls, fully transparent covers and sidewalls, flooring systems, rain gutters
• Available span widths: 6m, 8m, 9m, 10m
• Main profile: 100x48x3mm (4-channel)
• Typical uses: events, parties, weddings, exhibitions, sports
