Commercial tent Hexagon

receptiontransportablemultifunction

General Details
The Hexagon Tent is available in span options 6 m, 8 m, 9 m, 10 m and 12 m and offers two roof shapes: diamond and high peak. Standard eave heights are 2.6 m and 3.0 m. Main profiles include NPT-HEX PT-HEX-HP (82x48x3 mm), NPT-HEX-HP (100x48x3 mm), WT-HEX-HP (122x68x3 mm) and GT-HEX-HP (166x88x3 mm. The frame is manufactured from hard-pressed extruded aluminum alloy 6061/T6. The roof cover is PVC-coated polyester textile, 850 g/m², available in blackout or translucent variants. Installation and dismantling are straightforward and time-efficient. The structure is suitable for temporary or permanent use.

Optional inclusions

• PVC plastic side windows
• Glass windows
• Glass doors
• Ground anchors
• Weight plates
• Wooden floors
• Lining curtain

Product Specification (table)
Span Width | Eave Height | Ridge Height | Side Length | Main Profile
6 m | 2.6 m | 3.71 m | 3 m | 100x48x3 mm (4 - channel)
8 m | 2.6 m | 4.18 m | 4 m | 100x48x3 mm (4 - channel)
9 m | 2.6 m | 4.24 m | 4.5 m | 100x48x3 mm (4 - channel)
10 m | 2.6 m | 4.4 m | 5 m | 122x68x3 mm (4 - channel)
12 m | 2.6 m | 4.78 m | 6 m | 122x68x3 mm (4 - channel)

3D model
A 3D model of the 6-sided polygon tent is available for visualization.

Technical specifications

• Roof shapes: diamond and high peak
• Eave heights: 2.6 m and 3.0 m
• Frame material: hard-pressed extruded aluminum alloy 6061/T6
• Roof cover: PVC-coated polyester textile, 850 g/m², blackout or translucent
• Main profiles: 82x48x3 mm; 100x48x3 mm; 122x68x3 mm; 166x88x3 mm (various HP variants)
• Span options: 6 m, 8 m, 9 m, 10 m, 12 m
• Installation: quick installation and dismantle; suitable for temporary or permanent use
• Optional components: PVC side windows, glass windows, glass doors, ground anchors, weight plates, wooden floors, lining curtain
