Electric vehicle charging station 2663-030502-1201114ACfloor-mountedoutdoor
Add to favorites
Compare this product
Characteristics
- Options
- for electric vehicles
- Electrical characteristics
- AC
- Mounting
- floor-mounted, outdoor, cabinet
- Number of charging cable
- multiplace
- Output voltage
230 V
Description
Description LOCKEEL® e-bike charging station for secure outdoor storage and simultaneous charging of e-bike, pedelec and scooter batteries, as well as batteries for tools and technical equipment. The unit comprises 12 spacious compartments, each fitted with two protected sockets for safe charging in varied weather conditions.
Construction and protection The cabinet is constructed from moisture- and weather-resistant galvanised steel sheet with a UV-resistant stove-enamel finish. Double-walled doors and magnetic catches provide dust- and moisture-protected storage. Rubber bumpers reduce closing noise and ensure tight door contact. Upper compartments feature slightly lowered sockets for easier access.
Electrical equipment Each compartment contains 2 × IP54 sockets (230 V, 16 A) with built-in surge protection. Socket positions in upper compartments are offset downward for ergonomic access. The station also includes three service compartments positioned below the charging modules.
Base and installation Rust- and weather-resistant base with adjustable leveling feet ensures stable support. The base is prepared for secure anchoring to the foundation. A drilling template and installation manual are provided.
Quality features
Options and locking Available in various colours and locking variants. Standard equipment includes a PIN code lock for charging compartments and a cylinder lock for the service compartment. A master key for emergency opening is supplied.
Assembly instructions The unit must be installed on a stable concrete foundation of 126 x 62 cm (recommended depth 50 cm). Route a cable conduit through the centre of the foundation and provide a three-core power supply cable with a minimum cross-section of 2.5 mm². A drilling diagram for anchoring is included in the delivery. Follow the operating manual for detailed installation instructions.
Properties / Technical specifications
Construction and protection The cabinet is constructed from moisture- and weather-resistant galvanised steel sheet with a UV-resistant stove-enamel finish. Double-walled doors and magnetic catches provide dust- and moisture-protected storage. Rubber bumpers reduce closing noise and ensure tight door contact. Upper compartments feature slightly lowered sockets for easier access.
Electrical equipment Each compartment contains 2 × IP54 sockets (230 V, 16 A) with built-in surge protection. Socket positions in upper compartments are offset downward for ergonomic access. The station also includes three service compartments positioned below the charging modules.
Base and installation Rust- and weather-resistant base with adjustable leveling feet ensures stable support. The base is prepared for secure anchoring to the foundation. A drilling template and installation manual are provided.
Quality features
- Robust construction: body sheet thickness 1.0 mm; door thickness 1.5 mm
- Designed for outdoor use and weather-resistant charging
- Two protected sockets per compartment with surge protection
- Service compartment with cylinder lock as standard
Options and locking Available in various colours and locking variants. Standard equipment includes a PIN code lock for charging compartments and a cylinder lock for the service compartment. A master key for emergency opening is supplied.
Assembly instructions The unit must be installed on a stable concrete foundation of 126 x 62 cm (recommended depth 50 cm). Route a cable conduit through the centre of the foundation and provide a three-core power supply cable with a minimum cross-section of 2.5 mm². A drilling diagram for anchoring is included in the delivery. Follow the operating manual for detailed installation instructions.
Properties / Technical specifications
- GTIN / EAN: 0010101469033
- Number of charging compartments / doors: 12
- Compartment internal tray width: 40 cm
- Compartment internal tray height: 36.9 cm
- Compartment depth: 60 cm
- External dimensions (HxWxD): 215 cm x 126 cm x 63 cm
- Weight: 350 kg
- Material: galvanised steel sheet, UV-resistant stove enamel finish
- Sheet thickness: body 1.0 mm, doors 1.5 mm
- Sockets per compartment: 2 × IP54 sockets (230 V, 16 A) with surge protection
- Locking: PIN code lock (service compartment with cylinder lock as standard); master key included
- Base: rust- and weather-resistant, with leveling feet and prepared for ground anchoring
- Recommended foundation: concrete 126 x 62 cm, recommended depth 50 cm; power supply via centre conduit (three-core, min. 2.5 mm²)
