Shut-off valve CDS seriesslidewith handwheelfor water
Add to favorites
Compare this product
Characteristics
- Type
- slide
- Operation
- with handwheel
- Function
- shut-off
- Media
- for water
- Body
- flange, stainless steel
- Applications
- for the chemical industry, for the food industry
- Other characteristics
- compact, corrosion-resistant
- DN
Min.: 50 mm
(1.969 in)Max.: 1,400 mm
(55.118 in)- Pressure
Min.: 2 bar
(29 psi)Max.: 10 bar
(145 psi)- Temperature
120 °C
(248 °F)
Description
double-sided sealing with continuous valve plate and smooth dead zone-free flow
ensures unobstructed closing with densities <5% and media containing solids
also available with various seal types and surface treating of the wearing parts - see type CDSV and CDSR
areas of application:
media with a high consistency, a high level of stickies and rejects
nominal diameters:DN 50 – 1400 (2 – 56“)
material:stainless steel (1.4404 / 1.4571)
flanges:DIN EN 1092-1, ANSI B 16.5 class 150
seal:NBR, Viton, EPDM and other
