Transformer current sensor ACT-0073

ACsplit-core

ACT-0073 Current Sensor ACT-0073 Amp Current Sensor with 5 Amp Output The ACT-0073 (previously MAG-J73C005) is a split-core current transformer with input rating of 500 – 1000 Amps. It outputs a corresponding 5A output. This split-core transformer is made with high quality nickel lamination’s. Split-core transformers are ideal for installation on existing electrical wiring by snapping around the conductor. The ACT-0073 has a self-locking mechanism. Frequent Applications •Power meter •Switchgear •Distributed measurement systems •General Sets •Control panels ACT-0073 | Features ● Input up to 1,000 Amps ● Output 5A at rated current ● Accuracy at 5% to 120% of rated current at frequency of 50 Hz to 60 Hz ● UL Registered, CE and RoHS compliant ● 6 FT, 18 AWG leads ACT-0073 | Description “The Magnelab ACT-0073 was previously marketed as the MAG-J73C005. It is a split core current transformer that has a 500 Amp to 1,000 Amp input rating. The output on this AC current sensoris 5 Amp and it is constructed using high quality nickel lamination. Split core transformers like this one are perfect to be installed on wires that have already been installed. It easily and readily clips on around the conductor thanks to the self-locking mechanism. The AC current transformer can be used on switch gears, power meters, general sets, distributed measurement systems and control panels. The ACT-0073 comes with up to Class 0.5 accuracy for up to 2.5VA and a Class 1 accuracy for up to 10VA. The system voltage is 720 V or 0.72 kV. It can withstand overload of 1.2 the rated current, on a continuous basis.
