Signal amplifier GSV-3BT
for strain gauge sensorssingle-channelIP66

signal amplifier
signal amplifier
signal amplifier
Add to favorites
Compare this product


Other characteristics
for strain gauge sensors, single-channel, IP66

Max.: 1,000 Hz

Min.: 1 Hz


1- channel straingauge amplifier in grouting-housing; connection: round connector; dimensions: 120mm x 80mm x 55mm; input sensitivity: 2 mV/V; interface: wireless interface via Bluetooth®; data rates: from 1Hz to 1000Hz; Standby: 40h; supply voltage: 9V..37V DC; 1x M12 female socket for sensor connection; 1x M8 flange socket (male) for connection charger / external power supply; resolution: 16 Bit; weight: 390 g; environmental protection: IP66; The GSV 3BT M12 is suitable for connection of full bridge strain gauges, strain gage half bridges and strain gage quarter bridges (350 Ohm) . DIL switch the input is configured for full-, half-and quarter-bridge, 120/350/1000 ohms or voltage input With the integrated 2.6 Ah battery the run time is approximately 8 hours. By breaking the connection of the GSV-3BT is in stand-by mode offset with a power consumption of about 1mA Optional 4 x 2.6 Ah battery in the unit cover are integrated. The accessories (Bluetooth USB stick) is not included.


12 Pages
