Food, Power, Gas & Bellows; Cryogenic, Nuclear, Oil & Bellows; Gas, Chemical, Water Treatment
DESCRIPCIÓN:
STAINLESS STEEL, COPPER AND PLASTIC PIPES
AND MULTITUBES
– Stainless Steel and Carbon Steel Pipes
– Copper Pipes
– Copper pipes with PVC insulation
– Multipipes, steam traced and electric traced pipes
ASTM A 269 corrosion resistant, seamless, general purpose austenitic stainless steel tubing.
Austenitic stainless steel tubes ASTM A 213 seamless for boilers, superheaters and heat exchangers.
Pressure calculations are based on ASME B31.3 in accordance with ASTM A213 / A269 tolerances.
Certified tests:
Flaring tests.
Rockwell surface hardness < B90.
Crush test.
Hydrostatic test.
COPPER:
Annealed copper tubes :
ASTMB68/ASTMB75
ASTM B 88 (Type K / Type L)
Black PVC coated copper tubes:
ASTMB68/ASTMB75
Chemical characteristics (Table 1. ASTM B 68, ASTM B 75 and ASTM B 88).
Copper UNS No. C12200
Minimum Copper % 99.9
Phosphorus % 0.015 to 0.040
Calculations made from ASME B31.3 specifications based on a minimum copper stress of 30 Ksi in accordance with the diameter and wall thickness tolerances for each standard.
