Circular saw TIGER 402 CNC HR 4.0 RC

miterfor metalsfor profiles

TIGER 402 CNC HR 4.0 RC, non-ferrous circular saw with TCT blade for aluminium and alloys, with programmable head mitering trough MEP CNC 40 controller. – Automatic vertical circular saw powered by brushless motor mitering from -45° to +45° and up to +60° in semiautomatic mode. This machine can be equipped with the bar loader CB6001 (OPTIONAL) for rounds, square and rectangle materials according to technical specifications. It can also be retrofitted. – 8” touch screen controller with self learning programming. – Saw head mitering with high precision positioning (max 1’ of degree) powered by a brushless motor and pneumatic locking of saw head once positioned. – The headstroke, according to the dimensions of the material which has to be cut, is set directly from the control panel. – Head down stroke by means of electromechanical cylinder to obtain the maximum cutting rigidity. – Shearing stress control. – Automatic device to lubricate the blade only when the machine is cutting. – Rotation pin with thrust bearing to grant rotation precision and stability. – Machine base with chip tray and equipped to connect chip collector (optional). – Pneumatic double locking vice. – Pneumatic vertical vice.
