Turbine flow meter IC-HBTfor waterfor oilfor beer

turbine flow meter
turbine flow meter
turbine flow meter
Add to favorites
Compare this product
indicative price

Characteristics

Technology
turbine
Fluid
for water, for oil, for beer
Other characteristics
4-20 mA, high-accuracy, precision, with battery, low-pressure, with alarm function, stainless steel, in-line, clamp-on
Applications
for the pharmaceutical industry, for the food industry, for harsh environments, sanitary, for wastewater treatment, for medical applications
Process pressure

Min.: 10 bar (145.04 psi)

Max.: 16 bar (232.06 psi)

Process temperature

Min.: -40 °C (-40 °F)

Max.: 230 °C (446 °F)

Volumetric flow rate

Min.: 2 l/min (0.5 us gal/min)

Max.: 2,250 l/min (594.4 us gal/min)

Description

Designed specifically for use within hygienic environments; the Metri IC-HBT Hygienic Turbine Flow Meter is ideal to use in the Brewing, Food Processing and Pharmaceutical industries. The HBT offers a high level of accuracy and durability as well as being easy to install. It is perfectly suited to applications that will be handling liquids in a hygienic process. The Metri IC-HBT Hygienic Flow meter comes complete with hygienic Tri Clamp and RJT connections. All wetted parts are precision machined from solid stainless-steel with no castings. This provides excellent long-term viability, even in harsh conditions. The HBT is manufactured to an extremely high standard for use within hygienic environments as standard; electro-polishing is also offered as an optional extra for applications that require an additional level of finish. Everything has been thought of in the manufacture of the Metri Hygienic Turbine Flow Meter; especially cleaning and maintenance. The bearings of the meter can be easily cleaned by using low pressure steam and chemical in place (CIP); essential where components can be difficult to reach when in-situ. Typical liquid food installations include: Syrups Water Vegetable Oils Foodstuffs Vinegars Typical HXX applications include: Metering Metri IC-HBT Hygienic Turbine Flow Meter Features: Hygienic Tri Clamp & RJT connections Solid stainless-steel construction Electro-polish optional finish Low pressure steam clean Compatible with IC-LPS Flow Switch Specification The Metri IC-HBT Hygienic Turbine Flow Meter is accurate and highly reliable across a wide range of gas types and applications.
