Water pump GNH electricself-priminggear
Add to favorites
Compare this product
Characteristics
- Fluid
- water
- Operation
- electric
- Priming
- self-priming
- Technology
- gear
- Mobility
- stationary
- Domain
- industrial
- Applications
- handling, high-precision
- Material
- stainless steel, PTFE
- Other characteristics
- large, OEM, flow, rugged
- Flow
Max.: 42.8 l/min
(11.30656 us gal/min)Min.: 12.25 l/min
(3.23611 us gal/min)- Pressure
Max.: 103 bar
(1,493.889 psi)Min.: 6.9 bar
(100.076 psi)- Fluid temperature
Max.: 121 °C
(249.8 °F)Min.: -46 °C
(-50.8 °F)- Weight
8.4 kg
(18.52 lb)
Description
The GNH Series pumps can handle tough fluid handling needs without taking up too much space. These cavity style gear pumps provides smooth, pulseless delivery and can withstand system pressures to 103 Bar (1500 psi). Designed using higher displacement gears, these pumps are configured to provide optimum flow with 4-pole motor speeds not exceeding 1750rpm. These designs allow for large plant systems to use common motors across a wide range of products.
GNH Series pumps deliver rugged, reliable performance for any high-precision pumping need.
Product Features
Smooth, Pulseless Delivery
Chemically Resistant
Easy to Service
Proven Reliability
Advanced Pump Technology
Wide Range of Options
OEM Configurations
High-System Pressure Capability
Enhanced Efficiency
Displacement Range
Gear Set G35: 24.5 ml/rev
Construction
Magnetic Drive Gear Pump
Cavity Style
Helical, Shafted Gears
Sleeve Bushings
O-ring Seals
Wetted Materials
Base Materials
316 Stainless Steel/Titanium
Gears
PTFE
PEEK
Static Seals
PTFE
