Diesel generator set GE 5000 HBM
single-phaseportable50 Hz

Diesel generator set - GE 5000 HBM - MOSA - single-phase / portable / 50 Hz
Diesel generator set - GE 5000 HBM - MOSA - single-phase / portable / 50 Hz
Add to favorites
Compare this product

Characteristics

Motor type
diesel
Phase
single-phase
Portability
portable
Frequency
50 Hz
Cooling system
air-cooled
Applications
industrial
Emissions level
Stage V
Power in kVA

4 kVA, 4.9 kVA
(5.44 hp, 6.66 hp)

Rated capacity

3.6 kW, 4.4 kW
(4.9 hp, 6 hp)

Voltage

230 V

Rotational speed

3,000 rpm
(18,850 rad.min-1)

Noise level

71 dB, 96 dB

Fuel tank capacity

5.3 l
(1.4 gal)

Length

650 mm
(26 in)

Width

490 mm
(19 in)

Height

520 mm
(20.47 in)

Weight

56 kg
(123.46 lb)

Description

Portable generating set - Honda petrol engine with recoil starter - Single-phase alternator - Single-phase power 4 kVA (3.6 kW) TECHNICAL FEATURES • Stand-by single-phase power: 4.9 kVA (4.4 kW) • PRP single-phase power: 4 kVA (3.6 kW) • Frequency: 50 Hz • Sockets: 1x 230V 16A 2P+T CEE - 1x 230V 16A 2P+T Schuko • Overload thermal shut off • Engine shut down for low oil level GENERAL SPECIFICATION • Tank capacity: 5.3 lt • Running time (75% of PRP): 3.3 h • Measured acoustic power LwA (pressure LpA): 96 dB(A) (71 dB(A) @7m) • Dry weight of machine: 56 kg • Dimensions (LxHxW): 650 x 520 x 490 mm
