Diesel generator set GE 7000 BBMsingle-phaseportable50 Hz
Add to favorites
Compare this product
Characteristics
- Motor type
- diesel
- Phase
- single-phase
- Portability
- portable
- Frequency
- 50 Hz
- Cooling system
- air-cooled
- Applications
- industrial
- Emissions level
- Stage V
- Power in kVA
5.5 kVA, 6.7 kVA
(7.48 hp, 9.11 hp)- Rated capacity
5 kW, 6 kW
(6.8 hp, 8.2 hp)- Voltage
230 V
- Rotational speed
3,000 rpm
(18,850 rad.min-1)- Noise level
74 dB, 99 dB
- Fuel tank capacity
6.6 l
(1.7 gal)- Length
770 mm
(30 in)- Width
520 mm
(20 in)- Height
650 mm
(25.59 in)- Weight
75 kg
(165.35 lb)
Description
Portable generating set - Briggs&Stratton petrol engine with recoil starter - Single-phase alternator - Single-phase power 5.5 kVA (5 kW)
TECHNICAL FEATURES
• Stand-by single-phase power: 6.7 kVA (6 kW)
• PRP single-phase power: 5.5 kVA (5 kW)
• Frequency: 50 Hz
• Sockets: 1x 230V 32A 2P+T CEE - 1x 230V 16A 2P+T CEE
• Engine shut down for low oil level
• Ground Fault Interruptor (optional)
GENERAL SPECIFICATION
• Tank capacity: 6.6 lt
• Running time (75% of PRP): 2.5 h
• Measured acoustic power LwA (pressure LpA): 99 dB(A) (74 dB(A) @7m)
• Dry weight of machine: 75 kg
• Dimensions (LxHxW): 770 x 650 x 520 mm
