Synchronous motor EM820600 Vpermanent magnetIP67
Add to favorites
Compare this product
Characteristics
- Type
- synchronous
- Voltage
- 600 V
- Configuration
- permanent magnet
- Protection class
- IP67
- Applications
- for power steering
- Power
2.2 kW
(2.99 hp)- Torque
33 Nm
(24.339551 ft.lb)- Rotational speed
1,500 rpm
(9,424.778 rad.min-1)- Operating temperature
Max.: 80 °C
(176 °F)Min.: -40 °C
(-40 °F)
Description
Product Overview
The EM820 is a permanent magnet synchronous motor (PMSM) engineered for electric power steering pump applications. Rated power 2.2 kW at 1500 RPM with dual DC voltage compatibility (336VDC/600VDC), IP67 protection and 33 N·m peak torque. Compact design; weight 11.5 kg.
Key Highlights
Electrical Specifications
Parameter — Value
Rated Power — 2.2 kW
Rated Voltage — 336VDC / 600VDC
Peak Torque — 33 N·m
Rated Speed — 1500 RPM
Protection Class — IP67
Weight — 11.5 kg
Ambient Temperature — -40~80°C
Part Number — EM820
Mechanical Drawing
Mechanical drawing available showing dimensional and mounting details for integration into steering systems.
Technical specifications
The EM820 is a permanent magnet synchronous motor (PMSM) engineered for electric power steering pump applications. Rated power 2.2 kW at 1500 RPM with dual DC voltage compatibility (336VDC/600VDC), IP67 protection and 33 N·m peak torque. Compact design; weight 11.5 kg.
Key Highlights
- 2.2 kW rated power at 1500 RPM
- 336VDC / 600VDC supply voltage
- 33 N·m peak torque
- IP67 ingress protection
- Suitable for electric power steering pump integration
Electrical Specifications
Parameter — Value
Rated Power — 2.2 kW
Rated Voltage — 336VDC / 600VDC
Peak Torque — 33 N·m
Rated Speed — 1500 RPM
Protection Class — IP67
Weight — 11.5 kg
Ambient Temperature — -40~80°C
Part Number — EM820
Mechanical Drawing
Mechanical drawing available showing dimensional and mounting details for integration into steering systems.
Technical specifications
- Rated Power: 2.2 kW
- Rated Voltage: 336VDC / 600VDC
- Rated Speed: 1500 RPM
- Peak Torque: 33 N·m
- Protection Class: IP67
- Weight: 11.5 kg
- Ambient Temperature Range: -40~80°C
- Part Number / Model: EM820
