Bellows vacuum pad

circularsiliconerubber

Product Name Vacuum pad for eggs φ40mm

Overview Suitable for processes from egg collection to egg processing. Shape and lip structure are designed for stable suction of chicken eggs. Options include fluorine coating, specialized holders and flow restriction holders to adapt to different line layouts.

• ApplicationsEgg collection
• Egg processing and handling

Category Vacuum Pad

• SpecificationsBrand: PISCO (NIHON PISCO)
• Product type: Vacuum pad for handling eggs
• Typical applications: egg collection and egg processing
• Product code (page reference): VP40EGG
• Pad material: silicone rubber
• Pad hardness: 30° (black), 40° (clear)
• Pad size: φ40mm
• Holder type: direct-mount fixed (vacuum outlet on top)
• Pad connection: push-fit (direct connection) — dedicated for eggs
• Vacuum outlet sizes (holder): M10x1.5, G1/8
• Options: fluorine coating, flow-restriction holder, holders with anti-suction mechanism (patent pending)
• Notes: holder with anti-suction mechanism reduces egg-fluid ingress but regular cleaning is recommended
• Compliance: Food Sanitation Law / FDA (parts in contact with workpiece (egg)), RoHS2

Options & environmental measures

• Flow path (pad holder) option without copper-containing metals (uses stainless steel)
• Ozone resistance: seal materials HNBR or FKM available for low-concentration ozone environments
• Fluorine coating option to reduce adhesion and ease cleaning

Other information
Available as pad only, holder only (with anti-suction mechanism), or pad+holder sets. Related videos and FAQ provide installation, usage precautions, failure causes and countermeasures, and material resistance guidance (see page FAQ).
